PCI-QUAD04 User's Guide
Termination resistors
Although termination resistors typically are not required, SMT pads on the PCI-QUAD04 are open and labeled
to allow you to install terminating resistors from the various inputs to ground.
Input
Phase A+
Phase A-
Phase B+
Phase B-
Index+
Index-
Installing the PCI-QUAD04
After configuring the PCI-QUAD04, install the board in your computer. Follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the
MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on installing
the software.
1.
Turn your computer off and open it up.
2.
Close your computer and turn it on.
If you are using an operating system with support for plug-and-play (such as Windows 2000 or
Windows XP), a dialog box opens as the system loads, indicating that new hardware has been detected. If
the information file for this board is not already loaded onto your PC, you are prompted for the disk
containing this file. The Measurement Computing Data Acquisition Software CD supplied with your board
contains this file. If required, insert the disk or CD and click
3.
To test your installation and configure your board, run the InstaCal utility installed in the previous section.
Refer to the Quick Start Guide that came with your board for information on how to initially set up and
load InstaCal.
Connecting the board for I/O operations
Connectors, cables – main I/O connector
Table 2-3
lists the board connectors, compatible cable, and compatible accessory products for the PCI-
QUAD04.
I/O connector type
Compatible cable
Table 2-2. Termination resistor settings
1
2
R9
R22
R10
R23
R11
R20
R12
R21
R14
R19
R13
R18
Table 2-3. Board connectors, cables, and accessory equipment
37-pin connector
C37F-4X9F-1M
Channel
3
R38
R39
R36
R37
R35
R34
.
OK
2-3
Installing the PCI-QUAD04
4
R30
R31
R28
R29
R27
R26
