11. Annexes

11.1 Daikin DMS502A51 BACnet Gateway for Daikin Air Conditioning VRV system

This gateway allows connecting up to 256 VRVs in 4 groups of 64 (with the corresponding
cards). It is important to consult Daikin documentation to configure successfully the
integration.
The signals available for every VRV internal unit are showed in the following list. As an
example, a selection of Addresses for internal points in the gateway have been selected,
and also the appropriate values for fields R/W and A/D (depends on the object type of every
signal). Note that Property field must be always 85-Present Value.
Object Type Property
4-Binary Output 85-Present Value 1-StartStopCommand_000
3-Binary Input 85-Present Value 2-StartStopStatus_000
3-Binary Input 85-Present Value 3-Alarm_000
13-Multistate Input 85-Present Value 4-MalfunctionCode_000
14-Multistate Output 85-Present Value 5-AirConModeCommand_000
13-Multistate Input 85-Present Value 6-AirConModeStatus_000
14-Multistate Output 85-Present Value 7-AirFlowRateCommand_000
13-Multistate Input 85-Present Value 8-AirFlowRateStatus_000
0-Analog Input 85-Present Value 9-RoomTemp_000
2-Analog Value 85-Present Value 10-TempAdjust_000
3-Binary Input 85-Present Value 11-FilterSign_000
5-Binary Value 85-Present Value 12-FilterSignReset_000
5-Binary Value 85-Present Value 13-RemoteControlStart_000
5-Binary Value 85-Present Value 14-RemoteControlAirConModeSet_000
5-Binary Value 85-Present Value 16-RemoteControlTempAdjust_000
3-Binary Input 85-Present Value 20-CommunicationStatus_000
2-Analog Value 85-Present Value 22-AirDirectionCommand_000
0-Analog Input 85-Present Value 23-AirDirectionStatus_000
4-Binary Output 85-Present Value 24-ForcedThermoOFFCommand_000
3-Binary Input 85-Present Value 25-ForcedThermoOFFStatus_000
4-Binary Output 85-Present Value 26-EnergyEfficiencyCommand_000
3-Binary Input 85-Present Value 27-EnergyEfficiencyStatus_000
3-Binary Input 85-Present Value 28-ThermoStatus_000
3-Binary Input 85-Present Value 29-CompressorStatus_000
3-Binary Input 85-Present Value 30-IndoorFanStatus_000
3-Binary Input 85-Present Value 31-HeaterStatus_000
Doc: IntesisBox ASCII Server - BACnet IP client v10 r15 eng.pdf
© Intesis Software S.L.U. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SLU
ASCII Server - BACnet IP
Signal
User manual v10 r15 eng
Object instance Add R/W
1 2 1-W
2 3 0-R
3 4 0-R
4 5 0-R
5 6 1-W
6 7 0-R
7 8 1-W
8 9 0-R
9 10 0-R
10 11 2-R/W 0-Ana
11 12 0-R
12 13 2-R/W 1-Dig
13 14 2-R/W 1-Dig
14 15 2-R/W 1-Dig
16 16 2-R/W 1-Dig
20 17 0-R
22 18 2-R/W 0-Ana
23 19 0-R
24 20 1-W
25 21 0-R
26 22 1-W
27 23 0-R
28 24 0-R
29 25 0-R
30 26 0-R
31 27 0-R
URL http://www.intesisbox.com
email info@intesisbox.com
tel +34 938047134
A/D
1-Dig
1-Dig
1-Dig
0-Ana
0-Ana
0-Ana
0-Ana
0-Ana
0-Ana
1-Dig
1-Dig
0-Ana
1-Dig
1-Dig
1-Dig
1-Dig
1-Dig
1-Dig
1-Dig
1-Dig
