9. If set active, the "Who-Is" will be send to the Device assigned IP, if not set, the "Who-
Is" will be Broadcasted over the network. (Broadcasted is the standard method).
10. Enter the IP address for the gateway (supplied by the network administrator).
11. Enter the IP NetMask for the gateway (supplied by the network administrator).
12. Enter the Default Gateway address (router address) in case the gateway (IntesisBox) is
in a different sub network than other BACnet devices (supplied by the network
administrator). Leave this blank if there is no need of a router address.
13. Enter the Gateway BACnet device number (Default: 246).
14. Enter the Gateway BACnet device name (optional, just for identification purposes).
15. Select the priority to use in BACnet write operations: 1...16 (select "none" for no
priority).
16. Select the COV subscriptions life time. COV subscriptions will be renewed at a half of this
time. Select value zero (0) for non-time-limited COV's.
17. Enter the minimal difference of the new data received from BACnet to send a write to
ASCII (Values: 0..1; Example: 0.5).
