IntesisBox
4.
LinkBoxBacnet. Configuration & monitoring tool for IntesisBox
4.1 Introduction
LinkBoxBacnet is a Windows compatible software tool developed specifically to monitor and
configure IntesisBox BACnet IP series gateways. It is possible to configure all external
protocols available for IntesisBox BACnet IP and to maintain different customer's
configurations based on a LinkBoxBacnet project for every different installation. Maintaining
always on hard disk a copy of the last configuration files for every external protocol and
customer, that is to say for every project.
From LinkBoxBacnet, as well as configure the integration signals list and connection
parameters for every external protocol, it is permitted also to select the serial port to use to
connect to the gateway and the use of some tools for monitoring and debugging de device.
Some of these tools will be explained in this document but only some of them, the rest of
available debugging tools and commands will not be explained here because they are for
exclusive use under the recommendations of Intesis Software technical support.
LinkBoxBacnet allows configuring all IntesisBox BACnet IP series independently of the
external system or protocol used. For every external system, LinkBoxBacnet has a specific
configuration window. Periodically, new free versions of LinkBoxBacnet are released
incorporating the latest developed integrations for external systems.
4.2 Project definition
The first step to do, in LinkBoxBacnet for a new installation, is to create the installation's
project giving a descriptive name to it. When you create a project, a new folder is created
with the name of the project containing the configuration files needed depending on the
external protocol selected for the project. It is strongly recommended that you create a new
project for every installation, if not, overwriting of configuration files of previous
installations using the same external protocol may occur, loosing the configuration data for
those previous installations. The projects folder is located in AppFolder\ProjectsBacnet,
where AppFolder is the installation folder of LinkBoxBacnet (by default C:\Program
Files\Intesis\LinkBoxBacnet). Inside the projects folder, a new folder will be created for
every project defined in LinkBoxBacnet with the files needed for the project.
When you open LinkBoxBacnet, the project selection window will appear inviting you to
select a project or create a new one. A demo project for every external protocol supported
is provided with the standard installation of LinkBoxBacnet. You can create a new project or
select a demo project based on the external protocol desired, and create a new one from
the demo one selected.
Doc: IntesisBox ASCII Server - BACnet IP client v10 r15 eng.pdf
© Intesis Software S.L.U. - All rights reserved
IntesisBox is a registered trademark of Intesis Software SLU
ASCII Server - BACnet IP
User manual v10 r15 eng
URL
http://www.intesisbox.com
email
info@intesisbox.com
tel
+34 938047134
Page 12 of 36
