4.4 Zero Offset
In this menu item, a constant positive or negative value can be set. This value is
automatically added to the measured value or subtracted from the measured value
every time a measurement is carried out. The display then shows the addition or the
difference. Moreover, the zero offset setting is always indicated below in the display
as a reminder.
This measuring mode is useful when determining the upper coating layer of a multi-
layer system. If the lower layer(s) is (are) known and show an adequately uniform
thickness, the coating thickness of this (these) layer(s) can be set as a negative
offset value. The display then only shows the thickness of the top layer.
When measuring coated rough metal surfaces, this mode can also be selected. In
this case, the roughness effect, which is determined on the basis of the uncoated
rough metal surface, is set as a negative offset value. The instrument will then
display the coating thickness above the peaks of the rough surface.
Setting Zero Offset Value
1. Press DOWN. Calibration appears on the display.
2. Press OK. Zero Setting appears on the display.
3. Press DOWN twice. Zero Offset appears on the display.
4. Press OK. Offsets appears on the display.
5. Press OK. Set Offset Value appears on the display.
6. Press UP or DOWN repeatedly until the required offset value appears on the
display.
7. Press OK. Offset Has Been Set appears on the display briefly, followed by the
start display with - - - -.
Deleting Zero Offset Value
1. Press DOWN. Calibration appears on the display.
2. Press OK. Zero Setting appears on the display.
3. Press DOWN twice. Zero Offset appears on the display.
4. Press OK. Setting of Offset appears on the display.
5. Press DOWN. Deletion of Offset appears on the display.
6. Press OK. Offset Deleted appears briefly, followed by the start display with the
four dashes - - - -.
© Checkline-Europe
-12-
5.0

SETTING AUDIBLE LIMIT ALERTS

To monitor your measured values, you can set an upper and a lower limit value.
This setting is useful during the measurement, for the evaluation of the measured
values later when displaying the single values or for the printout of measured values
If the limit value is exceeded or if it's not reached, an audio signal will sound, and a
warning note will appear on the display (_ or _).
Setting
1. Press DOWN repeatedly until Limits appears on the display.
2. Press OK. Limits Setting appears on the display.
3. Press OK again. Set Lower Limit appears.
4. Press UP or DOWN repeatedly until the desired lower limit value appears on the
display.
5. Press OK. Set Upper Limit appears on the display.
6. Press UP or DOWN repeatedly until the desired upper limit value appears on the
display.
7. Press OK. Limits have been set will appear briefly, then the start screen
with - - - -.
Deleting
1. Press DOWN repeatedly until Limits appears on the display.
2. Press OK. Limits Setting appears.
3. Press DOWN until Deletion of Limits appears.
4. Press OK. Limits Deleted appears briefly, followed by the start screen
with - - - -.
© Checkline-Europe
-13-
