Chapter 8
The Scope Multimeter function allows you to perform multiple types of circuit and component
measurement tests. This chapter includes general operation procedures, instructions for saving
and reviewing test data, optional settings, and general reference information.

8.1 Overview

The Scope Multimeter test functions are:

Digital Multimeter (DMM)

•
Graphing Multimeter (GMM)
•
Lab Scope
•
8.1.1 Digital Multimeter (DMM)
The digital multimeter gives you the ability to quickly make precise common electrical
measurements (e.g. DC and AC voltage, resistance and amperage) on circuits and components
to verify operation. The meter displays measurements in a digital numerical format, and is typically
used for measuring signals that are not rapidly changing.
The DMM is ideal for performing basic tests on most standard automotive circuits, and displays
the results in a large easy to see format.
To use the DMM, select the Scope Multimeter icon from the home screen then select Digital
Multimeter from the menu. See
available testing functions.
Specifications
Function
Signal
Measurement
VDC (Full Scale)
VAC (Full Scale)
Signal
Measurement
Input Impedance
Ohm Measurement
Diode Test
Continuity Test
Ohms
Glitch Capture
Diode test
Scope Multimeter
Tests and Capabilities (Quick
Range
Ch. 1— (yellow jack)
75VDC
50VAC
10 MΩ
Ch. 1— (yellow jack (–))
Ch. 2— (green jack (+))
40 Ω—4 MΩ
Approximately 50 µS
2V scale
67
Reference)‚ on page 70 for a list of
Accuracy/Comments
Input is referenced to common ground
(GND— (black jack)
Do not measure greater than 75VDC
Do not measure greater than 50VAC (rms)
-
-
Fixed scales or auto ranging
-
-
