Table 4-1 Scanner toolbar buttons (part 2 of 2)
Button
Record
Clear
Sort
Trigger
Zoom
Custom Data List
View
Lock/Unlock
Save
Tools
Previous Point
Next Point
Previous Screen
Next Screen
Icon
Indicates the data being displayed is paused and not
being updated. Selecting resumes data collection.
Erases all the data in the buffer and begins a new
recording. Selecting opens a confirmation message.
Determines the order in which the data parameters
are listed on the screen.
Opens a menu that allows you to set, arm, and clear
threshold values that automatically trigger a data
movie recording.
Incrementally increases and decreases the scale of
the data being displayed.
Opens a menu for selecting which parameters
display in the data list.
Switches the screen viewing mode between a
parameter list and a data graph display.
Locks or unlocks the highlighted parameter. Locked
parameters move to the top of the list and do not
scroll as you move through the data.
Saves the current screen information, along with the
data stored in the buffer, to tool memory.
Opens the tools menu, which allows you to adjust
basic tool settings.
Moves back one data point with each button push
when viewing recorded or paused data. Hold the
button down to keep moving back through the data .
Moves one data point with each button push when
viewing recorded or paused data. Hold the button
down to keep moving back through the data.
Moves back one complete screen at a time when
viewing recorded or paused data. Hold the button
down to keep moving back through the data.
Moves back one complete screen at a time when
viewing recorded or paused data. Hold the button
down to keep moving forward through the data.
18
Scanner Navigation
Function
