ShopStream Connect
If the ShopStream Connect software does not open, open it from the Windows Start menu or use
the ShopStream Connect shortcut icon on the Windows desktop (automatically created during
installation).

13.2 SSC Main Screen

The ShopStream Connect software will open automatically when you connect the diagnostic tool
to your PC USB connection,
The following shows the main screen layout for ShopStream Connect software.
1— Notes Window—allows you add notes to select data files. Select Save from the menu bar
2— File directory structure—displays the file directory structure of your PC in standard
3— Data Manager Toolbar—provides control icons that perform a variety of operations on
4— Main Menu bar—contains File, Edit, Tools, and Help menus.
5— Tabs—provides access to data files and presets stored on the diagnostic tool or on the
Using SSC (Connecting to your
4
3
2
1
to save your notes. NOTE: Not all file types allow notes, the Notes window will be grayed
out when a file type that does not support notes is highlighted. Some image files may
display notes for reference purposes (the notes are grayed out and not editable).
Windows format, and shows any connected diagnostic tools at the bottom of the data list.
data files.
PC, and also allows viewing of software revision details of the diagnostic tool.
5 6 7
Figure 13-2
146
SSC Main Screen
PC)‚ on page 145,.
