Adjusting the Board to Factory Settings on T-REX
T-REX™ Jr.
Follow these troubleshooting instructions to ensure your T-REX
Step 1:
Remove back cover by unscrewing the 4 screws.
Step 2:
Remove front cover by unscrewing the 3 screws.
Step 3:
The board should look like the one in
the following positions:
• Knob 1: 3 o'clock
• Knob 2: 2 o'clock
• Knob 3: 8 o'clock
• Knob 4: 9 o'clock
• Knob 5: 9 o'clock
If your board does not match this, use a Philips screwdriver to adjust the knobs to these settings.
Step 4:
Put the front and back covers back on.
Figure
K
is running optimally.
™
K. The notches on the knobs should be set to
and
™
TS-TREX-09/02/15 • PAGE # 6
