6. Value name: displayed in the main and auxiliary displays is shown in the upper left corner of each
screen. We will see in Chapter IV, how to change the displayed value.
7. Sensor direction: An easy-to-remember small symbol indicates the direction of the force applied
to the sensor: tensile and

5. Touch area on the Measure screen

Each area of the measurement screen provides access to the configuration menus of the force gauge.
Stop test
CENTOR TOUCH Force Gauge – STAR / DUAL version
compression
Test
Tare
Set
points
- 8 -
Instructions Manual – V6.10
Main MENU
Send
Statistics
Validated
Help
