Buzzer

1.
Buzzer: Activates the buzzer for alarm conditions.
Beep Key: Activates the beeper when you touch the touch panel. Provides tactile touch to the user.

2. ECO Mode:

Reduces power consumption. Useful for long test times and USB communication.

3. Times out settings.

You can adjust individually times for sleep and power down.
Times out Sleep: Individually adjustable times for sleep. The CENTOR Touch will go to sleep after this
time. Separately set times for battery and charger. Touch the selected time to display keypad. Erase
then enter new time in seconds then touch the check key on the keypad.
Times out Screen: Individually adjustable times for display back light power down. Separately set
times for battery and charger. Touch the selected time to display keypad. Erase then enter new time
in seconds then touch the check key on the keypad.

4. Orientation

You can rotate the display of your CENTOR Touch by 90 degree increments. Touch the running man
picture to select orientation.

5. Language.

Touch the language picture to select desired display language.
Touch the check key to exit and save settings or the "x" key to exit with no save.
XII.

MAINTENANCE Panel

The maintenance panel allows access to basic test and control functions. Select the maintenance
symbol from the setup panel
