XIII.
ASSOCIATED PRODUCTS
1. Acquisition software
ANDILOG TECHNOLOGIES has developed several programs to save and analyse values.
You want to analyse values on a chart: RSIC software has been developed to this.
You want to capture the values graph and use graphics tools: CALIGRAPH software goes further in
tests analysis.
If you wish to connect your CENTOR TOUCH force gauge to a PC via one of our programs, contact
your ANDILOG TECHNOLOGIES dealer.
2. Interface Cables
Several interface cables can be used with CENTOR TOUCH force gauge:
External pedal: allows simulation of a keyboard button
Cable for external contact: allows force calculation from closing /opening of contact (equipped with
male-female plugs):
Linking cable for motorised test stand STENTOR allows to stop the stand according to a condition
defined by CENTOR TOUCH force gauge:
Cable for analogue link (with male-female plugs): links your gauge to another system
Cable for RS232 link: connect your gauge to a computer using the RS232 output
Multifunction cable test stand STENTOR control and RS232 link
Cable for USB connection: connect your gauge to a computer using the USB output
CENTOR TOUCH Force Gauge – STAR / DUAL version
- 31 -
Instructions Manual – V6.10
