CYBEX CardioTouch 770T Installation Instructions Manual page 6

6. Remove the CardioTouch screen and clean the area with a clean cloth and rubbing alcohol.
1
Install CardioTouch screen
1. Place the CardioTouch board in place in the handset.
1
2. Install the ground cable with a screw in the location shown and tighten by hand.
3. Install the remaining six screws by hand.
4. Tighten the seven screws in the order shown to 4 in-lbs (0.45 Nm) using a torque screwdriver.
2
4
Tighten Screws In This Order
Description
1 Clean this area
Description
1 Handset
2
Screws (7)
3 Ground cable
4 CardioTouch board
3
2
6
4
1
7 5 3
Page 6 of 11
