ANTAIRA STF-502C series Quick Installation Manual

©2013
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.

Introduction

The STF-502C series is a dual fiber converter for serial
transmission. The fibers may be cascaded to form a
daisy chain, or looped to form a ring. Ring topology
provides added protection in case of a single fiber link
breakdown.

Features

 Extends serial transmissions to 2km, 30km or 60km
 Supports fiber daisy chain or ring connections
 Redundant dual power inputs (12, 24, 48VDC)
 Supports dual fiber link redundancy
 Supports RS-422, RS-485(2/4 wire), RS-232
transmission to dual fiber connections.
 Enhanced serial baud rate up to 1024kpbs
 2.5KV isolation for serial signals
 Supports relay output for power or link failure
warning
 Hardened housing with IP30 protection
 Fan-less and DIN-Rail design for harsh industrial
environments
 Selectable terminator and adjustable pull high/low
resistor for RS-422/485 transmission

Specifications

Optical Interface

 Connector : SC or ST
 Fiber Optical rate : 50.00Mbps
 Fiber Port : Two fiber ports
 Fiber Type : MM 2km or SM 30km/60km
 Wavelength : MM 1310nm, SM 1310, 1550nm
 Point to Point Transmission : Half or Full duplex
 Ring Transmission : Half / Full duplex, self-healing
Quick Installation Guide
STF-502C series
Industrial RS232/422/485 Serial-Dual Fiber Converters
Specifications (cont.)

Electrical Interface

 Serial Connectors : RS-422/RS-485(5 pin terminal)
Rs-232(DB9 Female)
RS-485 : 4w, 2w, RS-422 : 4w
 RS-485 direction : Automatically detected
 Copper Baud rate : 50 up to 1024Kbps
 Serial Isolation : 2.5KV for serial signals
 Surge Protection : 8KV ESD for serial signals
 Pull High : selected by 10 position rotary switch
 Pull Low : selected by 10 position rotary switch
 120 ohm terminator : Option by Dip switch
Power
 Power Input : 12, 24, 48 VDC (9.6 ~ 58VDC)
 Power Reversal Protection : Yes
 Over Current Protection : Signal Short Together

Protected

 Terminal Block for Power and Alarm : Yes

Mechanical

 Water & Dust Proof : IP30 Protection
 Dimensions : 106 x 39 x 142mm (D x W x H)
 Mounting : DIN-Rail, Wall Mount
 Weight : 720g (1.5 lb)

Environmental

 Operating Temperature :
 0°C ~ 60°C, -40°C ~ 75°C (enhanced model)
 Storage Temperature: -40°C ~ 85°C
 Humidity : 5 ~ 95% (non-condensing)
V1.1
