MCTRL4K Independent Controller
User Manual


www.novastar.tech
port/connected to Ethernet port
Screen unlocked/locked
/
E: Connection status of Ethernet ports
Blue: The connection works and the port serves as the master.
−
Gray: The port is not connected or the connection does not work.
−
Mark on the top corner of the icon: The connection works and the port is in
−
redundancy status.
F: Connection status of optical fiber ports
Blue: The connection works and the port serves as the master.
−
Gray: The port is not connected or the connection does not work.
−
Mark on the top-left corner of the icon: The connection works and the port is
−
in redundancy status.
4 Home Screen
