Terminal Identification - Altronix ALTV615DC4UL User Manual

Terminal Identification:

Terminal Legend
XFMR IN
+ OUT1 --- through
+ OUT4 ---
Enclosure Dimensions:
8.5"H x 7.5"W x 3.5"D
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIALTV615DC4UL
Function/Description
Low voltage AC input (24VAC 40VA or 50VA) from
UL Listed, class 2 plug-in transformer.
Positive and Negative adjustable DC outputs.
Up to (12VDC - 2.5 amp total continuous output), 12-15VDC 2 amp total continuous
output. (See specifications).
