ALTV615DC220 Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV615DC44M220
- 6-15VDC @ 4A
- Four (4) Fuse Protected Outputs.
ALTV615DC48M220
- 6-15VDC @ 4A
- Eight (8) Fuse Protected Outputs.
ALTV615DC416220
- 6-15VDC @ 4A
- Sixteen (16) Fuse Protected Outputs.
ALTV615DC616220
- 6-15VDC @ 6A
- Sixteen (16) Fuse Protected Outputs.
ALTV615DC1016220
- 6-15VDC @ 10A
- Sixteen (16) Fuse Protected Outputs.
Rev. 032306
ALTV615DC44CBM220
- 6-15VDC @ 4A
- Four (4) PTC Protected Outputs.
ALTV615DC48CBM220
- 6-15VDC @ 4A
- Eight (8) PTC Protected Outputs.
ALTV615DC416CB220
- 6-15VDC @ 4A
- Sixteen (16) PTC Protected Outputs.
ALTV615DC616CB220
- 6-15VDC @ 6A
- Sixteen (16) PTC Protected Outputs.
ALTV615DC1016CB220
- 6-15VDC @ 10A
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix ALTV615DC48CBM220
Summary of Contents for Altronix ALTV615DC48CBM220
-
Page 1: Installation Guide
- 6-15VDC @ 4A - 6-15VDC @ 4A - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. ALTV615DC48M220 ALTV615DC48CBM220 - 6-15VDC @ 4A - 6-15VDC @ 4A - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs. -
Page 2: Specifications
Overview: Altronix ALTV615DC220 Series DC CCTV Power Supplies provide 6-15VDC distributed via fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. ALTV615DC220 Reference Chart: Total Output 220VAC Output Number PTC Protected Fuse Current 50/60Hz Altronix... -
Page 3: Terminal Identification
6. Reinstall isolation barrier and Power Distribution Module (models with “M” suffix only). 7. Connect devices to terminals marked [1P - 1N] through [4P - 4N] on PD4/PD4CB board, [1P - 1N] through [8P - 8N] on PD8/PD8CB, [1P - 1N] through [16P - 16N] on PD16W/PD16WCB/PD16CB board, carefully observing correct polarity (Figs. - Page 4 Fig. 1 - ALTV615DC44M220 and ALTV615DC44CBM220 Input 220VAC, 50/60Hz, 0.5A Output Wiring used on ALTV615DC44CBM220 POWER SUPPLY BOARD Trimpot MAIN FUSE BARRIER Fig. 1a TRIMPOT CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard replace fuse with the same type and rating. Do not expose unit to rain or moisture.
- Page 5 Fig. 2 - ALTV615DC48M220 and ALTV615DC48CBM220 Input 220VAC, 50/60Hz, 0.5A Output Wiring used on ALTV615DC48CBM220 POWER SUPPLY BOARD Trimpot MAIN FUSE BARRIER Fig. 2a TRIMPOT CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard replace fuse with the same type and rating.
- Page 6 Fig. 3 - ALTV615DC416220 • ALTV615DC416CB220 • ALTV615DC616220 • ALTV615DC61CB220 ALTV615DC1016220 • ALTV615DC1016CB220 DC OUTPUTS Fig. 3a 4 5 6 7 8 12 13 COMMON OUTPUTS POWER SUPPLY PROTECTED OUTPUTS BOARD TRIMPOT PD16W 3.5A 250V used on models with CB suffix. Example: ALTV615DC416CB220 Input...
- Page 7 Enclosure Dimensions for: • ALTV615DC44M220 • ALTV615DC44CBM220 • ALTV615DC48M220 • ALTV615DC48CBM220 8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm) 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” 1.25” (15.24mm) 0.6” (31.75mm) (31.75mm) (15.24mm) 1” 1” (25.4mm) (25.4mm)
- Page 8 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV615DC220 Series E15R...
