ALTV615DC220 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV615DC44M220
- 6-15VDC @ 4A
- Four (4) Fuse Protected Outputs.
• ALTV615DC48M220
- 6-15VDC @ 4A
- Eight (8) Fuse Protected Outputs.
• ALTV615DC416220
- 6-15VDC @ 4A
- Sixteen (16) Fuse Protected Outputs.
• ALTV615DC616220
- 6-15VDC @ 6A
- Sixteen (16) Fuse Protected Outputs.
• ALTV615DC1016220
- 6-15VDC @ 10A
- Sixteen (16) Fuse Protected Outputs.
• ALTV615DC44CBM220
- 6-15VDC @ 4A
- Four (4) PTC Protected Outputs.
• ALTV615DC48CBM220
- 6-15VDC @ 4A
- Eight (8) PTC Protected Outputs.
• ALTV615DC416CB220
- 6-15VDC @ 4A
- Sixteen (16) PTC Protected Outputs.
• ALTV615DC616CB220
- 6-15VDC @ 6A
- Sixteen (16) PTC Protected Outputs.
• ALTV615DC1016CB220
- 6-15VDC @ 10A
- Sixteen (16) PTC Protected Outputs.
Rev. 032306
Advertisement
Table of Contents
Related Manuals for Altronix LTV615DC48M220
Summary of Contents for Altronix LTV615DC48M220
-
Page 1: Installation Guide
ALTV615DC220 Series CCTV Power Supplies Installation Guide Models Include: • ALTV615DC44M220 • ALTV615DC44CBM220 - 6-15VDC @ 4A - 6-15VDC @ 4A - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. • ALTV615DC48M220 • ALTV615DC48CBM220 - 6-15VDC @ 4A - 6-15VDC @ 4A - Eight (8) Fuse Protected Outputs. -
Page 2: Installation Instructions
ALTV615DC220 Series DC CCTV Power Supplies provide 6-15VDC distributed via fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. ALTV615DC220 Reference Chart: Total Output 220VAC Output Number Fuse Current 50/60Hz Altronix Output Current Protected Protected (max per Input Model Number Voltage (Power) Outputs... -
Page 3: Terminal Identification
6. Reinstall isolation barrier and Power Distribution Module (models with “M” suffix only). 7. Connect devices to terminals marked [1P - 1N] through [4P - 4N] on PD4/PD4CB board, [1P - 1N] through [8P - 8N] on PD8/PD8CB, [1P - 1N] through [16P - 16N] on PD16W/PD16WCB/PD16CB board, carefully observing correct polarity (Figs. - Page 4 Do not expose unit to rain or moisture. Output Wiring 220VAC Input 50/60 Hz Used on PTC Models (example: ALTV615DC44CBM220) Barrier ALTRONIX CORP. BKLYN., NY 11220 Power Supply XFMR XFMR Board Trimpot...
- Page 5 Fig. 3 ALTV615DC416220 • ALTV615DC416CB220 • ALTV615DC616220 • ALTV615DC61CB220 ALTV615DC1016220 • ALTV615DC1016CB220 CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard replace fuse with the same type and rating. Do not expose unit to rain or moisture. DC outputs common 1 2 3 4 5 6 7 8...
- Page 6 Notes: - 6 - ALTV615DC220 Series...
- Page 7 Enclosure Dimensions for: • ALTV615DC44M220 • ALTV615DC44CBM220 • ALTV615DC48M220 • ALTV615DC48CBM220 • ALTV615DC416CBM220 8.5” x 7.5” x 3.75” (215.9mm x 190.5mm x 95.25mm) 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” (15.24mm) 0.6” 1.25” (31.75mm) (31.75mm) (15.24mm) 1” 1”...
- Page 8 (25mm) (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. II1ALTV615DC220 Series B23Q MEMBER - 8 - ALTV615DC220 Series...
