ALTV615DCUL Series

CCTV Power Supplies

Installation Guide

Models Include:

ALTV615DC416UL

- 6-15VDC @ 4A

- Sixteen (16) Fuse Protected Outputs.

ALTV615DC616UL

- 6-15VDC @ 6A

- Sixteen (16) Fuse Protected Outputs.

Rev. 050404

For models with the factory installed 3-wire line cord

add suffix "3", e.g. ALTV615DC616UL3

ALTV615DC416ULCB

- 6-15VDC @ 4A

- Sixteen (16) PTC Protected Outputs.

ALTV615DC616ULCB

- 6-15VDC @ 6A

- Sixteen (16) PTC Protected Outputs.

More than just power.

Table of Contents

Do you have a question about the ALTV615DC616UL and is the answer not in the manual?

Page 1: Installation Guide
ALTV615DC416ULCB - 6-15VDC @ 4A - 6-15VDC @ 4A - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs. ALTV615DC616UL ALTV615DC616ULCB - 6-15VDC @ 6A - 6-15VDC @ 6A - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.
Page 2: Specifications
CCTV cameras, heaters, and other video accessories. ALTV615DCUL Reference Chart: Altronix Model Number ALTV615DC416UL 6 - 15VDC – 3.5A 0.9A ALTV615DC416ULCB 6 - 15VDC – 2.5A 0.9A ALTV615DC616UL 6 - 15VDC – – 3.5A 1.5A ALTV615DC616ULCB 6 - 15VDC – 2.5A 1.5A Specifications: Agency Listings: Features: •...
Page 3: Terminal Identification
Terminal Identification: Power Supply Board Terminal Legend Function/Description AC/AC Low voltage AC input. + DC – 6VDC -15VDC output. PD16W/PD16WCB - Distribution Module 1P - 16P Positive DC outputs. 1N - 16N Negative DC outputs. Fig. 1 CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard replace fuse with the same type and rating: 3.5A, 250V.
Page 4 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV615DCULSeries B22R - 4 -...
