Altronix ALTV2416300UL Installation Manuals page 8

Fig. 5 - ALTV2416300ULM
Fig. 6 - ALTV2416300ULCBM
- 8 -
1 2
Transformer
underneath
power distribution
board
1 2
Transformer
underneath
power distribution
board
Illuminated Power Disconnect
Circuit Breaker with manual reset
3 4 5 6 7 8
COMMON
OUTPUTS
PROTECTED
OUTPUTS
3.5A 250V
Illuminated Power Disconnect
Circuit Breaker with manual reset
3 4 5 6 7 8
COMMON
OUTPUTS
PROTECTED
OUTPUTS
3.5A 250V
9 10 11 12 13 14 15 16
N
P
9 10 11 12 13 14 15 16
N
P
Fig. 5a
Input
115VAC,
50/60Hz
Fig. 6a
Input
115VAC,
50/60Hz
ALTV2416UL Series
