ALTV2416 Series
CCTV Power Supplies

Installation Guide

Models Include:
ALTV2416
- 24VAC @ 8A (200VA) or
28VAC @ 7A (200VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416350
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416300M
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416600
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Sixteen (16) Fuse Protected Outputs.
Rev. 071712
ALTV2416CB
- 24VAC @ 8A (100VA) or
28VAC @ 7A (200VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416350CB
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416300CBM
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416600CB
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALTV2416CB and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix ALTV2416CB

Summary of Contents for Altronix ALTV2416CB

  • Page 1: Installation Guide

    ALTV2416 Series CCTV Power Supplies Installation Guide Models Include: ALTV2416 ALTV2416CB - 24VAC @ 8A (200VA) or - 24VAC @ 8A (100VA) or 28VAC @ 7A (200VA). 28VAC @ 7A (200VA). - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.

  • Page 2: Specifications

    Overview: Altronix ALTV2416 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via sixteen(16) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Sixteen (16) Output ALTV2416 Reference Chart: Altronix Model Number 24VAC ALTV2416 ----- 3.5A...

  • Page 3: Installation Instructions

    Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 10-12). Secure enclosure to earth ground. 2. Slide switch on PD board to OFF position for models ALTV2416 and ALTV2416CB (Fig. 1, pg. 4). Turn OFF main switch on all other models (Figs. 2-4, pgs. 5-7).
  • Page 4 Fig. 1 - ALTV2416 and ALTV2416CB PTCs used on ALTV2416CB FUSED POWER OUTPUTS INPUT FUSED POWER OUTPUTS INPUT COMMON POWER OUTPUTS COMMON POWER OUTPUTS Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 4 - ALTV2416 Series...
  • Page 5 Fig. 2 - ALTV2416350 and ALTV2416350CB PTCs used on ALTV2416175CB MAIN FUSE Illuminated Power Switch Input 115VAC, 50/60Hz, 2.7A Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV2416 Series - 5 -...
  • Page 6 Fig. 3 - ALTV2416300M and ALTV2416300CBM Illuminated Power Switch 4 5 6 7 8 12 13 COMMON OUTPUTS PROTECTED OUTPUTS Input 115VAC, 50/60Hz, 2.7A PTCs used on ALTV2416300CBM PD16W 3.5A 250V Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) - 6 -...
  • Page 7 Fig. 4 - ALTV2416600 and ALTV2416600CB PTCs used on ALTV2416600CB MAIN FUSE Illuminated Power Switch Input 115VAC, 50/60Hz. Voltage Selection Configuration 24VAC Output (Yellow) (Black) 28VAC Output (Black) (Yellow) ALTV2416 Series - 7 -...
  • Page 8 Notes: - 8 - ALTV2416 Series...
  • Page 9 Notes: ALTV2416 Series - 9 -...
  • Page 10 Enclosure Dimensions (H x W x D) for: • ALTV2416 • ALTV2416CB 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 7.25” (184.15mm) 3.625” (184.15mm) 1.25” (31.75mm) 3.5” (88.9mm) 0.6” 0.6” 1.25” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125”...
  • Page 11 Enclosure Dimensions (H x W x D) for: • ALTV2416300M • ALTV2416300CBM 8.5” x 7.5” x 3.75” (215.9mm x 191mm x 95mm) 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” 1.25” (15.24mm) 0.6” (31.75mm) (31.75mm) (15.24mm) 1” 1” (25.4mm) (25.4mm) 0.9”...
  • Page 12 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV2416 Series B26R...
