Installation Manual
ALTV2416 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV2416
- 24VAC @ 8A (200VA)
or 28VAC @ 7A.
- Sixteen (16) Fuse Protected Outputs.
• ALTV2416350
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Sixteen (16) Fuse Protected Outputs.
• ALTV2416300M
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (300VA).
- Sixteen (16) Fuse Protected Outputs.
• ALTV2416600
- 24VAC @ 28A (700VA)
or 28VAC @ 25A (700VA).
- Sixteen (16) Fuse Protected Outputs.
• ALTV2416CB
- 24VAC @ 8A (200VA)
or 28VAC @ 7A.
- Sixteen (16) PTC Protected Outputs.
• ALTV2416350CB
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Sixteen (16) PTC Protected Outputs.
• ALTV2416300CBM
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (300VA).
- Sixteen (16) PTC Protected Outputs.
• ALTV2416600CB
- 24VAC @ 28A (700VA)
or 28VAC @ 25A (700VA).
- Sixteen (16) PTC Protected Outputs.
Rev. 071712
Advertisement
Table of Contents
Related Manuals for Altronix ALTV2416350
Summary of Contents for Altronix ALTV2416350
-
Page 1: Installation Guide
- 24VAC @ 8A (200VA) or 28VAC @ 7A. or 28VAC @ 7A. - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs. • ALTV2416350 • ALTV2416350CB - 24VAC @ 14A (350VA) - 24VAC @ 14A (350VA) or 28VAC @ 12.5A (350VA). -
Page 2: Specifications
ALTV2416300M and ALTV2416300CBM: • Surge suppression. 8.5” x 7.5” x 3.75” (215.9mm x 191mm x 95mm). • AC power LED indicator. ALTV2416350, ALTV2416350CB, • Power ON/OFF switch (ALTV2416 and ALTV2416CB). ALTV2416600, and ALTV2416600CB: • Illuminated power disconnect circuit breaker with 13.5”... -
Page 3: Terminal Identification
4. Connect AC power to the black and white flying lead of the transformer(s) (Figs. 1-4, pgs. 4-6). Use 18 AWG or larger for all power connections. 5. Measure output voltage before connecting devices. This helps avoiding potential damage. Terminals marked [1P - 8P] are positive of the same polarity. CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting the output voltage. - Page 4 Black Black Lead Lead ALTV2416350 • ALTV2416350CB Fig. 2 - Used on PTC Models (example: ALTV2416350CB) ALTRONIX CORP. MADE IN USA BROOKLYN, NY 11220 24VAC or 28VAC fused output 1 (Follow same procedure using terminals 2P & N through 8P & N...
- Page 5 ALTV2416300M • ALTV2416300CBM Fig. 3 - Power Switch Used on PTC Models (example: ALTV2416300CBM) 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 outputs outputs...
- Page 6 Fig. 4 - ALTV2416600 • ALTV2416600CB Used on PTC Models (example: ALTV2416600CB) 24VAC or 28VAC fused output 1 (Follow same procedure using terminals 2P & N through 8P & N fused outputs 2 through 8) MAIN FUSE Power Switch 24VAC Output (Factory Set) 28VAC Output 115VAC input,...
-
Page 7: Enclosure Dimensions
Enclosure Dimensions (H x W x D approximate) 7.25” (184.15mm) 3.625” ALTV2416 and ALTV2416CB (184.15mm) 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 1.25” (31.75mm) 3.5” (88.9mm) 1.25” 0.6” 0.6” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm) 2”... - Page 8 (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV2416 Series F14Q...
