Installation Manual
ALTV2416UL Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV2416ULX
- 24VAC @ 7A (170VA)
or 28VAC @ 6A (1705VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416300UL
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416300ULM
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416600UL
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Sixteen (16) Fuse Protected Outputs.
Rev. 040506
ALTV2416ULCBX
- 24VAC @ 7A (170VA)
or 28VAC @ 6A (1705VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416300ULCB
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416300ULCBM
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416600ULCB
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV2416300UL
Summary of Contents for Altronix ALTV2416300UL
-
Page 1: Installation Guide
- 24VAC @ 7A (170VA) or 28VAC @ 6A (1705VA). or 28VAC @ 6A (1705VA). - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs. ALTV2416300UL ALTV2416300ULCB - 24VAC @ 12.5A (300VA) - 24VAC @ 12.5A (300VA) or 28VAC @ 10A (280VA). -
Page 2: Specifications
Overview: Altronix ALTV2416UL Series CCTV Power Supplies provide 24VAC or 28VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Sixteen (16) Output ALTV2416UL Reference Chart: Altronix Model Number 24VAC 3.5A/ ALTV2416ULX –... -
Page 3: Terminal Identification
2. Set power switch on power distribution board marked [PD] to OFF position for models ALTV2416ULX or ALTV2416ULCBX (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker to OFF position for all other models (Figs. 3a - 8a, pgs. 6 - 10). 3. - Page 4 Fig. 1 - ALTV2416ULX 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) Class 1 Outputs Class 1 Outputs MAIN FUSE non power-limited Primary Primary In-line Fuse In-line Fuse Input 115VAC, 50/60Hz...
- Page 5 Fig. 2 - ALTV2416ULCBX 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) 24VAC configuration Class 2 Not Wet/ Class 3 Wet 28VAC configuration Class 1 24VAC configuration Class 2 Not Wet/ Class 3 Wet...
- Page 6 Fig. 3 - ALTV2416300UL 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) MAIN FUSE 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P &...
- Page 7 Fig. 4 - ALTV2416300ULCB 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) MAIN FUSE 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P &...
- Page 8 Fig. 5 - ALTV2416300ULM Illuminated Power Disconnect Circuit Breaker with manual reset Fig. 5a 4 5 6 7 8 12 13 COMMON OUTPUTS PROTECTED Input OUTPUTS 115VAC, 50/60Hz Transformer underneath power distribution board 3.5A 250V Fig. 6 - ALTV2416300ULCBM Illuminated Power Disconnect Circuit Breaker with manual reset Fig.
- Page 9 Fig. 7 - ALTV2416600UL Fig. 7a Illuminated Power Disconnect Circuit Breaker with manual reset 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) MAIN FUSE non power-limited Green Lead (ground) Input...
- Page 10 Fig. 8 - ALTV2416600ULCB Fig. 8a Illuminated Power Disconnect Circuit Breaker with manual reset 24VAC or 28VAC Output 1 Follow same procedure using terminals 2P & N through 8P & N for outputs 2 through 8) MAIN FUSE non power-limited Green Lead (ground) Input...
- Page 11 Enclosure Dimensions (H x W x D): • ALTV2416300ULM • ALTV2416300ULCBM 8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm) 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” (15.24mm) 0.6” 1.25” (31.75mm) (31.75mm) (15.24mm) 1” 1” (25.4mm) (25.4mm) 0.9”...
- Page 12 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV2416UL Series D04R...
