Terminal Identification - Altronix ALTV615DC616UL Installation Manuals

Power Supply Board
Terminal Legend
AC/AC
+ DC –
PD16W/PD16WCB - Distribution Module
1P - 16P
1N - 16N
Fig. 1
CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard
replace fuse with the same type and rating: 3.5A, 250V. Do not expose unit to rain or moisture.
Door
Wire Strap
(from
Enclosure
to Door)
ALTV615DCUL Series

Terminal Identification:

Function/Description
Low voltage AC input.
6VDC -15VDC output.
Positive DC outputs.
Negative DC outputs.
Power Supply
Board
Fig. 1a
Trimpot
Power
Switch
Black Lead
115VAC input
50/60 Hz
White Lead
DC outputs
common
1 2 3 4 5 6 7 8
outputs
protected
For continuous protection against
PD16W
3.5A 250V
non
power-
limited
XFMR
Green
Lead
(ground)
Power-Limited Class 2
DC outputs
common
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
outputs
protected
outputs
PD16W
9 10 11 12 13 14 15 16
N
P
outputs
risk of fire replace fuses with
same type and rating.
XFMR
Used on PTC Models
N
(example: ALTV615DC416ULCB)
P
PTCs
