DB37 connector and pin out

Connector type
Compatible Cables
Compatible accessory products
Pin Signal Name
1 n/c
2 n/c
3 Port B7
4 Port B6
5 Port B5
6 Port B4
7 Port B3
8 Port B2
9 Port B1
10 Port B0
11 GND
12 n/c
13 GND
14 n/c
15 GND
16 n/c
17 GND
18 USB +5V Out
19 GND
37 D-Type, shielded
C37FF-x
C37FFS-x
C37FM-x
CIO-MINI37
SSR-RACK24
SSR-RACK08
CIO-ERB24
CIO-ERB08
Pin Signal Name
20 USB +5V Out
21 GND
22 Port C7
23 Port C6
24 Port C5
25 Port C4
26 Port C3
27 Port C2
28 Port C1
29 Port C0
30 Port A7
31 Port A6
32 Port A5
33 Port A4
34 Port A3
35 Port A2
36 Port A1
37 Port A0
