PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part. The number following the key number is the quantity needed for assem-
bly. Note: If a part is not in the hardware kit, check to see if it has been preassembled. Extra parts may be
included.
M8 Split M8 Washer M8 Curved M8 Acorn M8 Locknut
Washer (56)–2 (70)–3 Washer (24)–6 (15)–3
Nut (25)–4
M4 x 25mm M8 x 35mm Screw M8 x 50mm Carriage
Screw (71)–1 (65)–2
Bolt (64)–4
