3. Attach the other Stabilizer (4) to the Seat Frame
(1) with two M8 x 50mm Carriage Bolts (64), two
M8 Curved Washers (24), and two M8 Acorn
Nuts (25).
4. Orient the Seat (7), the Seat Post (8), and the
Weight Rack (9) as shown.
Attach the Seat (7) and the Weight Rack (9)
to the Seat Post (8) with three M8 Locknuts
(15) and three M8 Washers (70); start all the
Locknuts, and then tighten them. Note: The
Locknuts and Washers may be preattached to
the Seat.
3
4
7
8
9
8
25
24
25
24
1
4
64
70
15
70
15
