GETTING STARTED

QUICK START STEPS

To install the software do the following:
1. Install the AD7450A/AD7451
enclosed CD.
Ensure that the EVAL-SDP-CB1Z
from the USB port of the PC while installing the software.
The PC must be restarted after the installation.
2. Connect the EVAL-SDP-CB1Z
AD7450ASDZ/EVAL-AD7451SDZ
Figure 2. Screw the two boards together with the enclosed
nylon screw-nut set to ensure the boards connect firmly
together.
software from the
board is not connected
board to the EVAL-
board as shown in
AD7450A
AD7451
Figure 2. Hardware Configuration—Setting Up the
3. Connect the 9 V power supply adapter included in the
kit to connecter J702 on the
AD7451SDZ
4. Connect the
USB cable. For Windows® XP, you may need to search for
the EVAL-SDP-CB1Z
search for the drivers for the
prompted by the operating system.
5. Launch the
software from the Analog Devices subfolder in the
Programs menu.
9V PSU
EVAL-AD7450ASDZ/EVAL-AD7451SDZ
