Chapter 1. STRUCTURAL ELEMENT Alarm In/Out Jack Video In/Out Jack RS-485 In/Out Jack Power/Network LED Power In Jack RJ-45 Jack Camera Base Decoration Ring Camera Case Dome Cover Follow these steps to install your IP Fast Dome: 1. Familiarize yourself with the IP Fast Dome - (this page) 2.
Page 3
Chapter 2. FAST DOME CAMERA SETUP DIP Switch Setting Camera ID Switch Fan Power Switch Camera Function Switch Alarm Mode Switch Chapter 2-1. Fan Power Switch Turn the number 2 switch to ON position to activate the internal fan. This will maintain the temperature inside and make the electric parts longer life.
Chapter 2-4. Fast Dome ID Address Setting Refer Chart Up to 64 Fast Dome Camera can be serial linked in one system. Therefore each dome is addressed by ID switch located at the base of the Fast Dome. Below is the address setting for camera 1~64: 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5...
Page 5
Chapter 3-1. Embedded Mounting Step 1 Ceiling Preparation 1. Drill a 3/32" (2.4mm) hole at the center of the chosen area. 2. Use a pencil and a compass to mark a circle 6.7" (170mm) in diameter and cut the circle. Step 2 The Ceiling Ring 1.
Page 6
Step 5 Attach the Camera Body and Base 1. Reconnect the connection cable. 3. Turn camera body clockwise to tight position. 2. Attach camera body to base. 4. Tight the three screws to fix the camera body. Step 6 Connection 1.
Page 7
Chapter 3-2. Attached Mounting Step 1 Fix The Base 1. Turn the dome cover anti-clockwise. 4. Turn the camera cover anti-clockwise. 2. Separate the dome cover from camera. 5. Separate the camera body from the base. 3. Untighten the three screws from base. 6.
Step 4 Install Decoration Ring and Dome Cover 1. Put on Decoration ring to base. 3. Put on dome cover to camera body. 2. Tighten the three screws. 4. Turn dome cover clockwise to tight position. Note : After dome cover is attached, use glass-cleaning cloth to clean dome cover. Unclean dome cover may affect camera performance.
Page 9
The IP Installer form is displayed on the screen. Click this button to search the IP Fast Dome / Video Server in the LAN. List all the IP Fast Dome / Video Server found in the LAN. * Preparation before IP Assignment Always consult your network administrator before assigning the IP address to your IP Fast Dome / Video Server.
Page 10
* Assign the IP Address to IP Fast Dome Select the MAC address of your IP Fast Dome in the list. The MAC address is identical to the unit's S/N. Click the menu bar View/Property to open the Property Page for the selected item. After filling in the properties, chick the OK button to submit the settings for the unit and the settings are activated immediately.
* Verify the IP Address and Open the Home Page To access the Home Page of the selected unit, run the View/Open Web on the menu bar. If your browser is opened and automatically connected to the IP Fast Dome Home Page, it menas you have assigned an IP Address to the unit successfully.
Page 12
C:\> ping 192.168.0.200 Pinging 192.168.0.200 with 32 bytes of data: Request time out. Request time out. Request time out. Request time out. Ping statistics for 192.168.0.200: Packets : Sent = 4, Received = 0, Lost = 4 (100% loss) Approximate round trip times in milliseconds: Minimum = 0ms, Maximum = 0ms, Average = 0ms C:\>...
Chapter 4-3. Verify and Complete the Installation from Your Browser Start your browser and enter the IP Address of your IP Fast Dome in the location/address field. The IP Fast Dome Camera can support Microsoft Internet Explorer and Netscape. But the voice feature (Video Server / Network Camera only) can only be run under Microsoft Internet Explorer.
