- Page 1 MINI DOME CAMERA PIH-2422/2442 INSTRUCTION MANUAL...
- Page 2 IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
- Page 3 PART DESCRIPTION & DIMENSION 62.2 Unit: mm VIDEO OUTPUT JACK DC12V POWER INPUT (DC12V 10%) JACK BASE INNER FIX RING OUTER FIX RING DOME LENS...
- Page 4 INSTALLATION 1. Attached Mounting Use the provided screws (M3.0x25, wooden screw) to screw 3 points of "a" on the base to mount it on the desired position. Please refer to FIG.1. 2. Embedded Mounting A. Disassemble base & inner fix ring and keep the ring only. Please refer to FIG.2.
- Page 5 FIG. 2 FIG. 3...
- Page 6 " " Mark FIG. 4 Attached Mounting " " Mark FIG. 5 Embedded Mounting...
- Page 7 SPECIFICATIONS COLOR MINIDOME CAMERA PIH-2422 3.6 PIH-2422 6 Model No. PIH-2442 3.6 PIH-2442 6 Focal Length 3.6mm 6.0mm 3.6mm 6.0mm F2.0 F1.8 F2.0 F1.8 Iris 44.5 44.5 Lens Angle of view 54.5 33.1 54.5 33.1 Power Input Voltage DC12V ( 10%)
- Page 8 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-2422CSE...
