D/N VANDAL RES. VARI-FOCAL IR DOME CAMERA
PIH-0746XW/0746XS
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PIH-0746XW and is the answer not in the manual?

Questions and answers

Summary of Contents for Lilin PIH-0746XW

  • Page 1 D/N VANDAL RES. VARI-FOCAL IR DOME CAMERA PIH-0746XW/0746XS INSTRUCTION MANUAL...
  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3 PART DESCRIPTION & DIMENSION 136.0 55.0 99.5 Unit mm BASE DOME COVER HOLE PLUG SIDE HOLE...
  • Page 4: Installation

    INSTALLATION 1. Please use the enclosed screw driver to untighten the 4 tamper-proof screws on the dome cover. 2. Put the provided screws (M3.0 x 25, wooden screw) through the holes marked as "a", and fix the base in the desired area (FIG.1).
  • Page 5 4. The direction of the lens is adjustable through the adjustable Pan/Tilt brackets and rotatable camera case. The lens can be adjusted easily by hand without using screw driver. Please refer to FIG.4. IRIS LEVER VR TILT SCREW DRIVER ZOOM ADJUSTMENT BRACKET FOCUS ADJUSTMENT FIG.
  • Page 6 6. Adjust DC iris level by turning the iris level VR. Please refer to FIG.4. ATTENTION: Adjust this VR with care so as not to cause damage to the unit. 7. Put on the dome cover first. Then tighten the tamper-proof screws (FIG.6).
  • Page 7 Alternative cabling positions 1. Untighten the hole plug on the bottom of the base and screw it to the side hole. 2. Put the video cable and power cable through the bottom hole and connect them to the terminal block on the PCB accordingly.
  • Page 8: Specifications

    SPECIFICATIONS D/N VANDAL RESISTANT VARI-FOCAL IR DOME CAMERA PIH-0746XWN/P PIH-0746XSN/P Model No. Focal Length 2.9~10mm 9~22mm F1.2 F1.5 Iris 94.6 ~ 28.8 30.6 ~ 13 Lens Angle of view 68.4 ~ 21.6 22.6 ~ 9.8 125 ~ 36 39.2 ~ 16.4 DC12V ( 10%) or AC24V ( Power Input Voltage System...
  • Page 9 MERIT LI-LIN ENT. CO., LTD http://www.meritlilin.com 66-074CSE...
