PARTS
Number
Description
-
-
Shell Headrest, Graphite
R35
015
10001
-
-
Shell Headrest, Titanium
R35
015
10002
-
-
Moving Support, Graphite
R35
029
10001
-
-
Moving Support, Titanium
R35
029
10002
-
-
Rod, Headrest
R20
061
10000
-
-
Screw, Socket, BTN HD 8-32 x 3/8
R04
111
10000
-
-
Spring Plunger - Headrest
R40
142
10000
abbb * F
-
Upholstery, Headrest, Gr. 1 Textile, Foam
H
abbb * F
-
Upholstery, Headrest, Gr. 2 Textile, Foam
H
abbb * F
-
Upholstery, Headrest, Leather 1, Foam
H
abbb * F
-
Upholster y, Headrest, Leather 2, Foam
H
-
-
Scr ew, Pan HD, Hi-Lo T orx #10 x 1/2
R04
195
10000
-
-
Barb Fastener
R20
198
10000
* Where a = Textile Code (W, V, S, L or P) (see p.49)
Wher e bbb = Color Code (see p. 49)
Note: All part numbers and prices are for single units only.
1. Remove three T20 screws securing the Headrest Cushion to the Headrest Shell.
2. Remove cushion from shell.
3. Slide the Headrest Shell to the highest position in the Moving Support.
4. Remove the two Allen screws on the bottom of the Headrest Rods.
5. Remove the two Barbed Fasteners from the top of the Headrest Rods.
6. Remove Headrest Shell.
7. Slide rods though the Moving Support until the tops are about 10mm into it and stop.
8. Push the new rods against the old rods and drive them though the Moving Support.
**** They must be removed this way so as to keep the Spring Plunger from pushing
though and jamming. ****
9. Re-assemble headrest in the reverse order of steps 6-1.
Quantity
Assembly
Headrest Rod Replacement
Unit
Per
Price
Comments
1
16.00
1
16.00
1
30.00
1
30.00
2
1.50
2
0.20
2
0.30
1
60.00
1
70.00
1
175.00
1
230.00
3
0.15
2
2.20
