I•Mark SX-32e Technical Manual Version: 8 Issue: 1
Printer Labelling
Product name and
Control Unit
TYPE
serial number SX-32e
0000
SER.No
Mfd by
Matthews Swedot AB
Gothenburg, Sweden
Certification
This printer is certified in accordance with the requirements for CE marking.
This equipment complies with the EMC Rules for a Class A (industrial environment)
computing device. Operation of this equipment in a residential area may cause
unacceptable interference to radio and TV reception.

About this Manual

This manual contains technical installation information specifically for the SX-32e
and only refers to print heads and ink supply units in general terms. For information
on specific print heads and ink supply units, please see the relevant documentation.
For information on basic procedures such as navigating the menu structure and
getting help, please see the Operator Manual.
It is important that the instructions in this manual are carried out in the order that they
appear.

Symbols Used

At the beginning of many of the instructions in this manual, an illustration showing a
row containing blocks of icons separated by arrows can be found. Each block depicts
a collection of icons (toolbar) which can be found at the bottom of the SX-32e
screen.
The illustration can look something like this:
This is the "path" you should follow, through the menu structure, to get to the
function described in the instruction which follows.
Voltage plate
100-240V A.C.
1,3 A
50-60 Hz
Mfd by Matthews Swedot AB
Gothenburg, Sweden
