Restoring Factory Settings - Matthews Marking Systems I-Mark SX-32e Technical Manual

I•Mark SX-32e Technical Manual Version: 8 Issue: 1
2 Select the desired display language and press OK.
The supported languages include:
English
Svenska
Deutsch
Français
Español
3 Note that the SX-32e is, by default, set up to use a single 8000-16v (8000 type, 16
valve) print head. To change this setting see "Print Head Configuration Settings"
on page 31.
The SX-32e is ready for use when the main screen is shown. See "Setting Up the
Control Unit" on page 20 to continue the installation procedure.

Restoring Factory Settings

Restoring factory settings will return the SX-32e to the state it was in when it was
delivered from our production facilities. This means that:
• all parameters, except date and time
below.
• all messages and message objects will be deleted.
1
Switch the control unit on.
2
When the main screen is shown, follow the above path.
3
Enter the class 3 password "!RESET".
4
When OK has been pressed the SX-32e will restore factory settings and show
the display language screen (see "Switching On for the First Time" on
page 42). Switching off at this point will cause the SX-32e to remain in the
factory settings state until it is switched on next time.
1. The date and time setting is retrieved from the real time clock which has bat-
tery backup
English Italiano
Swedish Nederlands
German Cesky
French Polski
Spanish Türkçe
1
, will return to their default settings. See
A P P E N D I C E S
Italian
Netherlands
Czech Republic
Polish
Turkish
43
