Page 34
Ctrl+gg 0 Use HOTKEY to redirect serial console ME1100 login: admin multiplexer to the BMC of the server. Password: admin ipmitool> ipmitool> lan set 1 ipsrc static Configure IP source to static for IOL1 FRU0. ipmitool> lan set 1 ipaddr 192.168.101.11 Define static IP address for IOL1 FRU0.
Page 35
ipmitool> lan print 1 Display the current network configuration Access Mode : Enable for IOL1 FRU0. IP Address Source : Static IP Address : 192.168.101.11 Subnet Mask : 255.255.255.0 MAC Address : 00:a0:a5:00:00:01 IP Header : TTL=0x40 Flags=0x40 Precedence=0x00 TOS=0x10 Default Gateway IP : 192.168.101.254 Default Gateway MAC : 00:00:00:00:00:00 802.1q VLAN ID : 4093...
Page 36
< > blue black bold blue italics > ...
Page 52
CPU_OSPrompt:~# ipmitool lan set 2 ipsrc static Configure IP source to STATIC for IOL2 FRU0. CPU_OSPrompt:~# ipmitool lan set 2 ipaddr 192.169.102.12 Define static IP address for IOL2 FRU0. CPU_OSPrompt:~# ipmitool lan set 2 netmask 255.255.255.0 Define netmask for IOL2 FRU0. CPU_OSPrompt:~# ipmitool lan set 2 defgw Define default gateway IP address for ipaddr...
Page 53
RemoteComputer_OSPrompt:~# ipmitool -I lanplus -H [BMC_IP] -U Configure IP source to STATIC for admin -P admin lan set 2 ipsrc static IOL2 FRU0. RemoteComputer_OSPrompt:~# ipmitool -I lanplus -H [BMC_IP] -U Define static IP address for IOL2 admin -P admin lan set 2 ipaddr 192.169.102.12 FRU0.
