For 1-Hi Case with a File (12"H) Drawer:

1.
Pull drawer outward (1a). Remove two (2) screws
in drawer (1b), then remove drawer from suspensions.
NOTE: Top of cabinet
removed from illustration
for clarity.
1b
1a
2.
Rotate the top of the suspension toward the center of the
cabinet to disengage (2a). Pull up to disengage the second
tab in front (2b). Push the suspension to the rear of the case
to disengage the hook in the back and remove (2c).
2a
2b
2c
