1-Hi 18" & 24" Deep Cabinets, 1.5-Hi 18"
& 24" Deep Cabinets Drawer/Drawer or
Open/Drawer and 2-Hi 18" & 24" Deep
Cabinets with c:scape or FrameOne Feet
(pages 2 - 3)
CAUTION
Please refer to the Steelcase Specification Guide
for Storage for additional guidance on determining
the correct counterweight package.
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2020 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Universal Storage 1-Hi, 1.5-Hi and 2-Hi
Lateral File Counterweight Package
NOTE: If you have a 1-Hi case with Feet or a 2-Hi case
with Feet which was manufactured prior to February 21,
2020, then RAACWR is required in addition to these
counterweights.
1.5-Hi 18" & 24" Deep Cabinets
Drawer/Open
(page 4)
#2
SQUARE
Page 1 of 4
P/N 1396566001
Doc # 148861 Rev A
Advertisement
Related Manuals for Steelcase 1-Hi
Summary of Contents for Steelcase 1-Hi
- Page 1 Cabinets with c:scape or FrameOne Feet (pages 2 - 3) NOTE: If you have a 1-Hi case with Feet or a 2-Hi case with Feet which was manufactured prior to February 21, 2020, then RAACWR is required in addition to these counterweights.
- Page 2 For 1-Hi or 1.5-Hi Case with a File Rotate the top of the suspension toward the center of the (12"H) Drawer or 2-Hi Case with cabinet to disengage (2a). Pull up to disengage the second tab in front (2b). Push the suspension to the rear of the case c:scape or FrameOne Feet: to disengage the hook in the back and remove (2c).
- Page 3 Rotate case assembly onto its back. NOTE: If you have a 1-Hi case with Feet or a 2-Hi case with Feet which was manufactured prior to February 21, 2020, then RAACWR COUNTERWEIGHTS is required in addition to these counterweights.
- Page 4 COUNTERWEIGHT For 1.5-Hi Case with a Box (6"H) Drawer Only: (Drawer/Open Configuration) NOTE: Top removed for clarity. NOTE: 1.5-Hi cases with only a 6” drawer require the same counterweight packages for Universal and Bases with Feet. Remove box drawer by performing similar procedure to steps 1 and 2 on page 2.
