Damage - Shipment/Installation - Zephyr AK7500BS Use, Care And Installation Manual

" m
2 6
" m
3 6
3 6 "
DUCTING
A minimum of 8" round or 3-1/4" x 10" rectangular
duct for dual internal blower.
Always use rigid type metal ducts only. Flexible
available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or
transitions and turns. If long duct run is required,
increase duct size.
If turns or transitions are required; install as far
away from hood duct output and as far apart,
between the two as possible.
Minimum mount height between range top to hood
bottom should be no less than 26".
Maximum mount height should be no higher than
36".
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
mounted too high will be hard to reach and will
If available, also refer range manufacturer's height
i n .
clearance requirements and recommended hood
a x .
mounting height above range.
Vertical Ducting:
Horizontal Ducting:
DAMAGE-SHIPMENT / INSTALLATION:
installation.
unit to the store in which it was bought for
repair or replacement.
or replacement is the responsibility of the
customer.
be made by arrangement between customer
and installer.
6
