Top View; Side View - Zephyr AK7500BS Use, Care And Installation Manual

Top View

**9 1/2"
or
***14 3/16"
6"
**7 7/8"
or
***10 3/8"
**7 7/8"
or
***9 15/16"
C/L
29 7/8" (30")
35 7/8" (36")
41 7/8" (42")
47 7/8" (48")
Back View
Ducting & Electrical Dimensions
C/L
11 9/16"
1 11/16"
*3 3/16"
**7 7/8"
***10 3/8"
*9 7/8"
**9 1/2"
***14 3/16"
2 3/4"
1 3/4"
8 9/16"
1 1/16"
11 9/16"
R 9/16"
**7 7/8"
or
***9 15/16"
10 3/4"
* Single Blower Rect. Ducting Dimension
** Single Blower Round Ducting Dimension
*** Dual Blower Dimension
8
www.zephyronline.com

Side View

**7 7/8"
or
***10 3/8"
12"
4"
24"
Back View
Mounting Dimensions
3 5/16"
1 11/16"
16 1/8"
13 5/8"
21 1/4"
27 3/8" (36" & 42"), 35 1/4" (48")
**1 15/16"
or
***4 5/16"
18"
16 7/8"
5 5/16"
