Q UI CK GUI DE
Thank you for purchasing da Vinci nano 3D printer. (Hereinafter referred to
as da Vinci nano. )This product is a small and portable 3D printer, you can
use da Vinci nano to take your imagination to a new level and bring any idea
to life.
Before you start printing, please read this manual to learn how to use da
Vinci nano correctly. This manual describes da Vinci nano safety instructions,
operating instructions, maintenance information and application tips. For
the latest information of da Vinci nano 3D printer, you can contact your local
Authorized Distributors or refer to the official website of XYZprinting. (http://
www.xyzprinting.com).
XYZmaker is a software that is used to operate the da Vinci nano and prepare 3D models for
Printing. Download XYZmaker from http://xyzptr.com/go2nano and install it on your computer.
First time installation requires an Internet connection.
ENG
HD23FNAX085
Table of Contents
2
3
6
7
9
10
Advertisement
Table of Contents
Related Manuals for XYZ Printing Da Vinci nano
Summary of Contents for XYZ Printing Da Vinci nano
- Page 1 10 www.xyzprinting.com). Troubleshooting XYZmaker is a software that is used to operate the da Vinci nano and prepare 3D models for printing. Download XYZmaker from http://xyzptr.com/go2nano and install it on your computer. First time installation requires an Internet connection. HD23FNAX085...
- Page 2 Product Overview Product Details 1. Top cover 5. Guide tube 9. Front cover handle 13. Power switch 2. Top cover latch 6. Detection head trigger 10. Feed module 14. USB port 3. Print bed 7. Extruder module 11. Filament holder 4.
- Page 3 Printer Setup Accessory Checklist 1. Quick Guide & Warranty Card 2. Feeding Path Cleaning Wire 3. Nozzle Cleaning Wire x 5 4. Scraper 5. USB Wire 6. Guide Tube 7. Bed Tape x 3 8. Cleaning Brush 9. Feeder 10. Power Adapter 11.
- Page 4 Printer Setup WARNING: Hazardous Moving Parts. Keep Fingers and Other Body Parts Away. Install the Guide Tube and Extruder Module Insert guide tube into the Press the white button and Follow the illustration to bend extruder module port. align the extruder module with the flat cable.
- Page 5 (with the the printer until horizontal. spool ring) on the spool holder. *If you have just unboxed the da Vinci nano, the sensor chip should Replace the New Filament Spool already be loaded. Separate the spool ring Use a Phillips head...
- Page 6 XYZmaker is a software that is used to operate the da Software Setup Vinci nano and prepare 3D models for printing. Download XYZmaker from http://xyzptr.com/go2nano and install it on your computer. First time installation requires an Internet connection. Load Filament Printing ＊...
- Page 7 Software Functional Descriptions Interface Introduction Extruder Filament Setting Extruder Filament Once this function is Please follow the on-screen selected, the nozzle will instructions. heat up automatically and The extruder module will move the nozzle to a proper automatically move to location where you can the working position.
- Page 8 Software Functional Descriptions Interface Introduction Setting Manually adjust the movement of X/Y/Z Axis for printer maintenance. 1. First click on Home Axes. Move extruder module rightwards and leftwards. Note The extruder module will be Jog Mode returned to the initial axis Move extruder module position.
- Page 9 Maintenance Z-offset Print bed calibration When the printing module has been moved, we Print bed level will affect the 3D printing quality, XYZprinting's 3D Printer has been adjusted to the recommend that you use z-offset. This function will best condition before leaving the factory. After long help you to adjust the printing distance between periods of use, the print bed level may change.
- Page 10 Troubleshooting Error Code Software interface Action Spool 1 Error. Please remove spool and install again. 0007 If errors persists, please contact service center for Reinstall or replace the filament cartridge. 0008 support. Heating Error. Please turn off the printer and contact Check whether the connections are connected properly and 0011 0014...
