    • SCS 4400 • SCS 4600 When used with the SCS 4400 or SCS 4600, the Cruizer II must have software version 2.3 or later. The Cruizer II console must be capable of CANbus communication in order to control an optional AccuBoom or AccuRow system.
  • Page 3: Introduction

    Introduction The Raven AccuBoom and AccuRow systems may be used with the Cruizer II guidance console to provide automatic boom or planter section control features. Note: Prior to using the AccuBoom or AccuRow feature with the Cruizer II console, the supporting machine specific hardware components must be purchased and installed.
  • Page 4: Accuboom Setup

    3. Use the number of sections slider to set the number of boom sections (max. of 10) on the implement. Cruizer II automatically divides the implement width (displayed in the lower, left information area) by the number of sections entered.
  • Page 5: Sprayer Setup

    Sprayer Setup From the home screen, touch Tools, and select the Sprayer icon in the Vehicle menu to access the Sprayer Screen. This screen allows the operator to customize the response of the AccuBoom system for the specific flow control hardware installed on the sprayer.
  • Page 6: Controller Setup Screen

    Controller Setup Screen Touch the Spray Control Setup icon in the lower, left corner of the Sprayer setup screen to view the Controller Setup screen. The Controller Setup screen allows the operator to select the AccuBoom control parameters for product application. Under most conditions, these settings will be set and not changed.
  • Page 7: Accurow Setup

    Planter Row & Section Setup Note: The Sections icon is only displayed in the Tools Menu if an AccuBoom or AccuRow node is connected to the Cruizer II CANbus. The Section configuration uses the programmed antenna Fore/Aft and Left/Right values to determine the relative location of each section with respect to the GPS antenna.
  • Page 8: Planter Setup Screen

    6. Use the number of sections slider to set the number of planter sections (max. of 16) on the implement. Cruizer II automatically divides the implement width (displayed in the lower, left information area) by the number of sections entered.
  • Page 9: Controller Setup Screen

    AccuRow Override The AccuRow override allows the operator to momentarily override the automatic planter section control feature and force all sections on. This may be useful to ensure complete seed coverage in point rows or when accelerating from a complete stop. Enable the AccuRow override feature and allow seed to travel to the knives before driving ahead.
  • Page 10: Guidance Screen

    Once the AccuBoom or AccuRow feature is configured, the Cruizer II console may be used to display boom or planter sections status during an active guidance session. Note: Refer to the Cruizer II Operation Guide for instructions on starting a guidance session. Coverage...
  • Page 11: Field Review Mode

    Field Review to switch to field review mode from the guidance display. Modes of Operation When used with the Cruizer II console, the AccuBoom and AccuRow features may be operated in one of the following modes: • Standard Mode • Zone Mapping Mode...
  • Page 12: Zone Mapping Mode

    Note: When creating a field boundary, the Cruizer II does not display the field boundary while driving and the completed boundary only appears in the Field Review Screen.
  • Page 13 5. To finish recording the boundary, touch Stop from the Mapping Tools Menu. Cruizer II will close the feature boundary by connecting the starting point and the current vehicle location with a straight line. While a guidance session may only contain a single field boundary, any...
  • Page 14: Reference Of Mapping Icons

    To resume recording the boundary, select the record field boundary icon from the boundary mapping menu. Select the Stop icon to close the boundary. Cruizer II will draw a straight line between the current vehicle location and the boundary starting point to close the boundary.
  • Page 15 To resume recording the boundary, select the record no plant zone boundary icon from the boundary mapping menu. Select the Stop icon to close the boundary. Cruizer II will draw a straight line between the current vehicle location and the boundary starting point to close the boundary.
  • Page 16 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
