E T C S o u r c e F o u r L E D Q u i c k G u i d e

Quick Setup

Step 1:
Step 2:
Step 3:
Individual features and settings are adjustable under the Advanced menu. Consult the User
Manual for more information on advanced features of Source Four LED fixtures.
Lustr +, Series 2 Lu str, Ser ies 2 Daylight HD, Ser ies 2 Tungsten HD, and Studio HD
Quick
Setup
General
Stage
High
Impact
Studio

Tungsten an d Daylight

Quick
Setup
Studio
Single
Channel
Stage
Sou rc e Fo ur LED Pr of i le
On the Main Menu, scroll to Quick Setups and press [
Scroll to the desired setup and then press [
An asterisk (*) indicates which setup is active.
Press [ ] to return to the home screen.
The top line of the home screen displays the name of the active setup.
Profile
Standard dimming curve,
Direct regulated output for color
consistency.
Incandescent dimming curve,
HSI regulated output for color
Plus 7 enabled consistency, 3200K white point
setting
Quick dimming curve, boost
RGB mode for maximum intensity,
5600K white point setting
Linear dimming curve,
Studio regulated output mode for
color consistency
Profile
Linear dimming curve, regulated
Studio
output for intensity stability
Standard dimming curve,
Direct regulated output for color
consistency
Incandescent dimming curve,
Direct
regulated output
Features
Features
Enables control of intensity from
luminaire's user interface; no console
required
For general purpose architectural use
Matches conventional luminaire
performance
Page 5 of 8
].
].
Recommended For:
Factory default: for general purpose
use, including interior architectural
applications
Theatrical lighting: duplicates the color
and dimming behavior of tungsten and
stage lighting fixtures
Event lighting: enables quick response,
simple RGB control and strobe channel
for maximum effect usage
Studio factory default: enables three-
parameter control of white light
(intensity, white point, and tint) via DMX
from a console or console-free fixture
display
Recommended For:
El ect r on ic T he at r e Con tr o ls , I nc.
Features
