TECHNICAL SPECIFICATIONS

ACOUSTICS
Subwoofer: 80W
Power handling
Mid-high speakers: 15W each
Subwoofer: 2Ω
Impedance
Mid-high speakers: 16Ω
45Hz – 19kHz (-10dB)
Frequency range
Subwoofer: 87dB
SPL 1W@1mt
Mid-high speakers: 82dB
Subwoofer: 100dB
Mid-high speakers: 92dB
Maximum SPL
(peak)
COVERAGE
Subwoofer: omni
Horizontal
Mid-high speakers: 140°
Subwoofer: omni
Vertical
Mid-high speakers: 20°
CROSSOVER
Internal digital crossover
Type
TRANSDUCERS
2 x 4" Ferrite Magnet with 1" voice coil
Low frequency
2 x 4" Passive Radiator
4 x 0.5" Neodymium Magnet with 0.5" voice coil
Mid-High frequency
AUDIO INPUT
Left: 3-pin phoenix
Analog Balanced
Right: 3-pin phoenix
3.5mm Jack Stereo
Analog Unbalanced
Fibre Optic Jack Connector
Optic
4 x USB 2.0
USB
4.1 Bluetooth Low Energy
Bluetooth
POWER AUDIO
OUTPUT
4-pin phoenix (Ch1-Ch2 PBTL config)
Subwoofer
Left: 2-pin phoenix (Ch3 BTL config)
Mid-high speakers
Right: 2-pin phoenix (Ch4 BTL config)
SPL
SPL
(continuos) - 106dB (peak)
SPL SPL
(continuos) - 98dB
SPL SPL
REMOTE
Wired Remote
2-pin phoenix
Control
5-pin phoenix (4 x GPIO ports)
Hardware Control
10-100 Mbps Ethernet (RJ45),
Network
Wirelss LAN 802.11n
DSP PROCESSING
192 kHz
Sample Rate
Bit Depth 32 bit
AMPLIFIER
4-channel Class-D audio amplifier
Type
4 x 50W @ 4Ω - 10% THD
Power
Subwoofer: 100 W @ 2Ω (Ch1-Ch2 PBTL config)
Mid-high out left: 50 W @ 4Ω (Ch3 BTL config)
Azimut Config
Mid-high out right: 50 W @ 4Ω (Ch4 BTL config)
PROTECTION
Output Short Protection
DC Offset
Overtemperature
Type
Undervoltage and Overvoltage
40V Load Dump
Open Ground and Power Tolerant
DC POWER
24Vdc - 5A
Operating range
2.5mm power jack
Connector
PHYSICAL
OVERVIEW
Mid-high: 2.2 x 10.0 x 1.2 cm (0.8"x 3.9"x 0.4")
Subwoofer: 50.0 x 11.6 x 10.1 cm (19.7"x 4.6"x 4.0")
Dimensions
Amplifier: 14.4 x 4.6 x 14.4 cm (5.7"x 1.8"x 5.7")
Remote: 2.2 x 10.0 x 1.2 cm (0.8"x 3.9"x 0.4")
Mid-high: 0.065 kg (0,14 lbs)
Subwoofer: 5.2 kg (11.46 lbs)
Weight
Amplifier: 0.5 kg (1.10 lbs)
Remote: 0.045 kg (0.10 lbs)
