K-array KK 50 Datasheet

KK50
3D line-array element
Features:
• Unique performance-to-size ratio
• Vertical, Horizontal and 3D line-array
applications
• Multiple 2" long-excursion full-range cone
drivers
• Wide horizontal coverage
• Electronically protected
• Integrated mounting hardware and accessories
• Selectable 16 Ohm or 64 Ohm impedance
• Selectable channel A or B
• Top quality components for outstanding
performance
• Weather proof, suitable for outdoor installations
• Available in black or white
Applications:
• Theatre, Club, Churches
• Front fi ll and under-balcony fi ll
• Portable and installed AV systems
• Stage and AV studio monitoring
The KK50 is a compact, line array element comprised of 8 x
2" neodymium transducers in a strong stainless steel chassis.
Its wide dispersion pattern can be confi gured horizontally
or vertically. A number of KK50 speakers can also be put
together in multiple array confi gurations.
Each speaker can be set for 16 or 64 Ohms eliminating the
need for 70volt transformers in distributed systems. The
KK50 reproduces the full vocal frequency range with clear
HP Sound Equipment s.r.l. Viale Roma 7/i - 50037 - San Piero a Sieve (FI), Italy
tel. +39 055 8487222 - fax. +39 055 8487238 - e-mail: info@k-array.com
DATASHEET
intelligibility. This can be augmented with the KKS50 or KL12
sub to extend the operating frequency range.
A variety of accessories provide numerous mounting options
for permanent and portable installations.
KA series amplifi ers have presets specifi cally optimized for
KK50 applications. All KK50 components are designed by
the K-array R&D department and custom made under the
K-array quality control system.
www.k-array.com
