Technical Specifications

General - KP52 I
Type Passive line array element
Transducers 6x 3.15" neodymium magnet woofers
Frequency Response 120 Hz - 18 kHz (-6 dB)
1
Frequency Response 70 Hz - 18 kHz (-6dB)
1.1
Max SPL 128 dB (peak)
2
Max SPL 116 dB (peak)
2.1
Rated Power 360 W
Coverage V. 10° - 45° | H. 90°
Nominal Impedance 8 Ω / 32 Ω selectable
SpeakOn NL4
Connectors 1+ 1- (signal); 2+ 2- (through)
Marine grade wiring - terminals red+ black- (signal)
Handling & Finishes
Material Stainless Steel
Colors Black, White, Custom RAL
Finishes 24K Gold, Polished, Brushed
IP Rating IP64
4
Dimensions (WxHxD) 89 x 520 x 118 mm (3.5 x 20.5 x 4.7 in)
3
Weight 5.8 kg (12.78 lb)
With dedicated natural preset.
1
With dedicated full-range preset
1.1
2 Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then
scaled at 1 m.
Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then
2.1
scaled at 1 m.
³ More complete water protection with K-IP65KITA and K-IP65KITB accessories (IP65
compliant)
20
General - KP102 I
Type Passive line array element
Transducers 12" x 3.15" neodymium magnet woofers
Frequency Response 120 Hz - 18 kHz (-6 dB)
1
Frequency Response 70Hz - 18 kHz (-6dB)
1.1
Max SPL 134 dB (peak)
2
Max SPL 122 dB (peak)
3
Rated Power 720 W
Coverage V. 7° - 30° | H. 90°
Nominal Impedance 4 Ω / 16 Ω selectable
SpeakOn NL4
Connectors 1+ 1- (signal); 2+ 2- (through)
Marine grade wiring - terminals red+ black- (signal)
Handling & Finishes
Material Stainless Steel
Colors Black, White, Custom RAL
Finishes 24K Gold, Polished, Brushed
IP Rating IP64
4
Dimensions (WxHxD) 89 x 1000 x 118 mm (3.5 x 39.4 x 4.7)
3
Weight 18.5 kg (40.8 lb)
With dedicated natural preset.
1
With dedicated full-range preset
1.1
2 Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then
scaled at 1 m.
Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then
2.1
scaled at 1 m.
³ More complete water protection with K-IP65KITA and K-IP65KITB accessories (IP65
compliant)
