KM312 - KM312P

11. TECHNICAL SPECIFICATIONS

11.1 KM312 DATASHEET

ACOUSTICS
Power handling 2000W +800W + 200W
Max Power 4000 W
Impedance 8 + 8 Ohm
Frequency range (-10
62 Hz – 19 kHz
dB)
SPL 1W/1mt LF:100dB HF:105dB
Maximum SPL 132dB (cont.) - 138dB (peak)
COVERAGE
Horizontal 100°-30° (depending on horn orientation)
Vertical 30°-100° (depending on horn orientation)
CROSSOVER
Type DSP controlled
Frequency 200Hz-1650Hz
TRANSDUCERS
2 x 12" Neodymium magnet woofer with
Low-mid frequency
2.5" voice coil
12" Neodymium magnet woofer with 3"
Mid frequency
voice coil
Neodymium magnet compression driver
High frequency
with 2" voice coil
Notes for data
1. Maximum RMS applicable power for a musical signal. The reference signal is the one proposed by EIAJ standard
2. With dedicated preset;
3. Measured @4 mt then scaled @1 mt;
4. Measured with musical signal
5. ( W x H x D)
New materials and design are introduced into existing products without previous notice. Present systems may differ in some respects from those presented in this catalogue.
(1)
(2)
(3)
(4)
AUDIO INPUT
Analog Connectors 2 male + 2 female 3-pin balanced XLR
Digital Connectors 1 male + 1 female 3-pin XLR
REMOTE
CONTROL INPUT
1 male + 1 female XLR parallel / 1 USB B Jack
Connectors
serial converter
POWER INPUT
Connectors 2 x PowerCon IN/OUT
AMPLIFIERS
Type 2 modules class D – DSP controlled
Power 4 x 1000W @ 8 Ohm
Dynamic limiter, over current, over temp., short
Protection
circuits
AC POWER
Nominal power
100 – 240 Vac ±10% 50-60Hz
requirements
Operating range 85 – 265 Vac (auto-range)
PHYSICAL
OVERVIEW
Dimensions 82.0 x 53.0 x 33.5 (47.95" x 20.47" x 13.18")
Wheight 37.5 Kg (82.67 lb)
Ver. 1.1
(5)
