Specifications And Options - Icom IC-M92D Instruction Manual

Specifications
■
D General
• Frequency coverage
• Mode
• Channel spacing
• Operating temp. range
• Current drain (at 7.4 V)
(approximately)
• Power supply requirement : 7.4 V DC norminal
• Frequency stability
• Antenna impedance
• Dimensions (approximately) : 61.2(W) × 141.4(H) × 43.2(D)mm
• Weight (approximately)

SPECIFICATIONS AND OPTIONS

: Tx 156.025–157.425 MHz
Rx 156.050–163.275 MHz
: FM (16K0G3E),
DSC (16K0G2B)
: ±25 kHz
: –20°C to +60°C
: TX high 1.5 A
Max. audio 0.50 A
(negative ground)
: ±10 PPM (–20°C to +60°C)
: 50 ˘ nominal
: 2.4(W) × 5.6(H) × 1.7(D) inch
(Projections not included)
: 295 g/10.4 oz with BP-275
D Transmitter
• Output power
• Modulation system
• Max. frequency deviation
• Adjacent channel power
• Spurious emissions
D Receiver
• Sensitivity (12 dB SINAD)
• Squelch sensitivity
• Intermodulation rejection ratio : 70 dB (typical)
• Spurious response rejection ratio:
• Adjacent channel selectivity : 70 dB (typical)
• Audio output power
All stated specifications are subject to change without notice
or obligation.
14
: 5 W/1 W
: Variable reactance frequency
modulation
: ±5.0 kHz
: 70 dB
: -68 dBc (typical)
: 0.25 µV (typical)
: 0.35 µV typical (at threshold)
70 dB (typical)
: 0.35 W typical at 10% distor-
tion with an 8 ˘ load (External)
: 0.7 W typical at 10% distortion
with an 8 ˘ load (Internal)
