Specifications - Altronix AL600ULX Installation Manual

The AL600ULX is a power supply that converts a 115VAC / 60Hz input, to a 12VDC or 24VDC regulating output
(see specifications below).
The AL600ULX is the base power supply unit for the UL Listed multi-output power supply/charger series:
AL600ULPD4, AL600ULPD4CB, AL600ULPD8, AL600ULPD8CB, AL600ULXPD16, AL600ULXPD16CB
(Refer to AL600ULX Series Power Supply Configuration Reference Chart below).
AL600ULX Series Power Supply Configuration Reference Chart:
AL600ULX(R)
AL600ULPD4
AL600ULPD4CB
AL600ULPD8
AL600ULPD8CB
AL600ULXPD16
AL600ULXPD16CB
Do not exceed total output rating of 6 amp per unit.
Input:
• Input 115VAC / 60Hz, 1.9 amp.
Output:
• 12VDC or 24VDC selectable output(s).
• 6 amp continuous supply current at 12VDC or 24VDC.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when
AC fails.
• Maximum charge current .7 amp.
Power Supply Output Specifications:
Output VDC Switch Position
12VDC SW1 CLOSED
24VDC SW1 OPEN
- 1 -
PD4UL 4 -
PD4ULCB 4 x
PD8UL 8 -
PD8ULCB 8 x
Two (2)
16 -
PD8UL
Two (2)
16 x
PD8ULCB
Overview:
- - 6
x - 3.5
- x 2.5
x - 3.5
- x 2.5
x - 3.5
- x 2.5

Specifications:

Battery Backup (cont'd):
• Zero voltage drop when switched over to
battery backup.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
• Battery presence supervision (form "C" contacts).
Additional Features:
• AC input and DC output LED indicators.
• Power supply, enclosure, cam lock and battery leads.
• All models are available in red enclosure
(add an "R" suffix to the part # e.g. AL600ULPD8R).
