Tcp/Ip Port Configuration; Gui Update - Octava UHD44MX-IP Install Manual

6.4 TCP/IP Port Configuration

IP address, subnet mask, and Gateway of UHD44MX-IP can be modified via GUI from
the above description, but beyond that users can configure the IP port, including IP
reset, password reset, and IP module firmware update on the WebServer.
Type the designed website (Default: 192.168.0.178:100, changeable) in your browser.
Enter correct username and password to log in the WebServer:
Username: admin; Password: admin
Here is the main configuration interface of the WebServer:
Figure 7- 16 TCP/IP Configuration

6.5 GUI Update

GUI for UHD44MX-IP supports online update in http://192.168.0.178:100. Type the
username and password (the same as the GUI log-in settings, modified password will
be available only after rebooting) to log in the configuration interface. After that, click
Administration at the source menu to get to Upload Program as shown below:
Figure 7- 17 GUI Update
