Octava HDMX44-V1.3 Installation Manual

Pro hd home theater series
Hide thumbs Also See for HDMX44-V1.3:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Enlarged version
Description
Model
HDMI Inputs
HDMI Outputs
Version
HDCP
IN/Out Connectors
RS-232 control port
Display Selection
Video Resolution
Video Data Rate
Deep Color Support
Vertical Frequency Scan Rate
Dimension
DC adapter (included)
Rackmount capable
Remote control (IR)
For Questions and support:
Email :
info@octavainc.com
URL: www.octavainc.com
Copyright© 2010 Octava Inc. All rights reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LL.C
All trademarks are the sole property of their respective companies
Specifications
HDMX44-V1.3
4
4
1.3
Yes
19 pin HDMI female type-A
1
Remote, Manual, Smart Scan
480 P, 720 I/P, 1080 I/P
6.75 Gbps
Yes
24 / 50 / 60 Hz
16.85 x 6.29 x 1.67 inch
(427.9 x 159.75 x 42.3 mm)
9VDC, 2.0A
1RU, Rack mounts included
Infrared, Discrete code
Rev.D
V 1.3
Deep Color
Installation Guide
